Modular Aluminum Stage Truss for Events 500kg Capacity
| 起源の場所 | 江蘇、中国 |
|---|---|
| ブランド名 | Shizhan |
| モデル番号 | アルミニウムトラスRT |
| 最小注文数量 | 100 |
| 価格 | $44-46 |
試供品およびクーポンのための私に連絡しなさい。
whatsapp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
心配があれば、私達は24時間のオンライン・ヘルプを提供する。
x商品の詳細
| 接続タイプ | ピン接続 | 負荷容量 | 500kg |
|---|---|---|---|
| 材料 | アルミニウム合金 | 単位長さ | 0.5m、1m、2m、3m、4m、5mまたはカスタマイズされる |
| トラスの形 | 正方形、三角形、円形またはカスタマイズされる | トリスセクション形状 | 正方形または円形 |
| トラスチューブの厚さ | 1.5/2/3mm | トラスチューブの直径 | 20mm、32mm、50mm |
| 硬度 | 16度 | 軽dutyトラス | 200*200mm 250*250mm |
| 中程度のトラス | 290*290mm、300*300mm; 350*350mm、300*400mm; 400*400mm; 450*450mm; 400*600mm | 重荷用トラス | 520*760mm; 600*760mm; 600*1000mm |
| メインチューブの厚さ | 30*2mm; 50*3mm; 50*4mm; 50*5mm | 副チューブの厚さ | 18*2mm 20*2.5mm 25*2.5mm |
| ブレースチューブの厚さ | 20*2mm; 25*2mm; 30*2mm | ||
| ハイライト | modular aluminum stage truss,aluminum lighting truss 500kg capacity,event truss with high load capacity |
||
製品の説明
Aluminium Stage Truss Structure Outdoor Stage Truss Design
Product Specifications
| Attribute | Value |
|---|---|
| Connection Type | Pin Connection |
| Feature | Durable |
| Frame design | Modular |
| Product Type | Display Truss |
| Application | Events, Concert, Music, Performance, DJ Band, Event, Exhibition |
| Welding | Welding |
| Load-bearing Capacity | 500kg |
| Assembly Method | Quick installation |
| Structure Type | Modular Structure |
| Material | Aluminum alloy |
| Unit length | 0.5m, 1m, 2m, 3m, 4m, 5m or customized |
| Color | Silver, black or customized |
| Truss section shape | Square or round |
| Shape | Square, Triangle, round or customized |
| Truss tube thickness | 1.5/2/3MM |
| Truss tube diameter | 20mm, 32mm, 50mm |
| Hardness | 16 degree |
Technical Details
Truss Material: Aluminum alloy 6082-T6
Light duty truss: 200*200mm; 250*250mm
Medium duty truss: 290*290mm, 300*300mm; 350*350mm; 300*400mm; 400*400mm; 450*450mm; 400*600mm
Heavy duty truss: 520*760mm; 600*760mm; 600*1000mm
Main tube thickness: 30*2mm; 50*3mm; 50*4mm; 50*5mm
Vice tube thickness: 18*2mm; 20*2.5mm; 25*2.5mm
Brace tube thickness: 20*2mm; 25*2mm; 30*2mm
Length: 0.5m/1m/1.5m/2m...4m or custom size
Truss type: Spigot or bolt
Truss Shape: Ladder truss, triangular truss, square truss, arch truss, circle truss
Color: Silver or black, blue, green...
Usage: Concert, new product release, fashion show, booth stand construction
Delivery Time: 10 working days
Applications
Our aluminum alloy stage truss is a modular system made of lightweight aluminum alloy tubes that can be easily assembled and disassembled. It is widely used in various events and applications:
- Concerts and festivals: Build stages for concerts, festivals, and outdoor events with configurable shapes and sizes
- Theatrical productions: Construct sets, backdrops, and structures for plays, musicals, and operas
- Exhibitions and trade shows: Create booths, displays, and exhibition structures
- Corporate events: Build stages and backdrops for product launches, conferences, and award ceremonies
- Sports events: Construct race start/finish lines, podiums, and scoreboards
Why Choose Our Products
- TUV, SGS, CE Certified products
- 15 years experience in truss, stage, barrier and scaffolding
- 35,000 m² workshop with excellent production capacity
- Professional engineering team for perfect project solutions
- Own aluminum profile production line for quality control
- Strict QC process with installation test before delivery
Frequently Asked Questions
How do I know your quality? Our products have TUV/SGS/CE/ISO9001 certificates and we offer samples for quality checking.
Payment methods: T/T, Western Union, Trade Assurance, L/C.
Warranty: 1 year warranty with free replacement for non-artificial damage.
Customization: Our technical team offers perfect solutions for custom projects.
